Lighting automation is the focus of this guide. The load decides compatibility. Smart lighting is the control layer around luminaires and drivers; Good results depend on load compatibility, circuit grouping and commissioning long before anyone names a scene in an app.
Quick answer
Interfaces need proof. Lighting automation can switch, dim, tune colour temperature or recall scenes from keys, sensors and schedules; the control protocol and driver must support the requested behaviour. A dimming command cannot fix an incompatible LED driver or a badly grouped circuit.
Understand
Read the adjacent technical page before choosing equipment. It may change the wiring, network or control method that belongs in the brief.
Loads decide compatibility. The lamp makes light; the driver regulates it; the control system tells the driver what level or state is wanted. If those three parts speak different electrical languages, the room may flicker, drop out at low level or refuse to dim at all.
Records preserve supportability. The schedule records lamp and driver model, wattage, control method, circuit quantity and expected minimum level; phase-cut, 0/1-10 V and DALI controls are not interchangeable labels.
Loads decide compatibility. A representative load should be tested when low-level performance matters; printed compatibility data comes first, then an actual sample settles the awkward edge cases.
Requirements come first. Occupancy and daylight logic should reduce needless operation without stealing control from the room user; manual overrides need a defined duration and a clear return to automatic mode.
Corridors, bedrooms and presentation rooms rarely deserve the same timeout. The scene schedule records those differences. The schedule should state each room use, trigger, delay, level and manual override so commissioning has a result that can be witnessed on site.
Interfaces need proof. DALI provides digital addressing, grouping, scenes and status queries for compatible lighting equipment. The DALI Alliance documents up to 64 control gear and 64 control devices on a subnet, but actual design also considers topology, bus supply and gateway limits.
Mechanical safeties stay authoritative. The luminaire and driver must support colour-temperature control, and the control system needs the matching device type; a warm-looking photograph is not a technical specification.
Loads decide compatibility. RGB mixes red, green and blue channels for coloured light. RGBW adds a dedicated white channel, which can give more useful white light than mixing colour channels alone. Both require matching multi-channel drivers, wiring and control addresses; neither should be specified where ordinary dimmable white light is the real need.
Movement needs clear limits. A motion detector is commonly tuned to larger movement, while a presence detector is intended to recognise finer occupancy within its rated pattern. Product terminology varies, so the design checks the sensing technology, mounting position and coverage diagram. A corridor can use short motion-based timing; a desk, bathroom or reading area often needs finer presence detection and a longer, tested vacancy delay.
Loads decide compatibility. Mixed drivers, loads below a dimmer minimum and incompatible control curves are common causes; circuit schedules and sample testing are cheaper than replacing a ceiling full of drivers after possession.
Scope sets the budget. Budget depends on circuit count, dimming method, driver compatibility, sensors, keypads, emergency-lighting boundaries, panel space and the number of scenes to programme. Relay control is a valid lower-complexity alternative where only on and off operation is needed. Addressable systems add flexibility and feedback, but also add commissioning, addressing and replacement compatibility work.
Failure needs a tested path. The sequence should include a luminaire and driver review before procurement, a representative dimming mock-up, circuit addressing, scene setting after finishes are visible and a final night-time review. Maintenance records should connect each fixture, driver and control address to its location. If a network, gateway or app is unavailable, physical controls should still provide the agreed basic response. Replacement drivers must be checked against the control method rather than selected only by wattage.
| Need | Method to investigate | Compatibility check |
|---|---|---|
| Simple on and off | Relay switching | Load current and inrush |
| Local dimming | Compatible phase or analogue control | Driver and low-end performance |
| Addressed groups and feedback | DALI | Certified gear, bus design and gateway |
